Imec, ASML, and TSMC Demonstrate 300mm Integration of Complementary 2D Transistors
Imec, ASML, and TSMC have demonstrated complementary 2D-material transistors at a 50nm contacted poly pitch on 300mm wafers using single-exposure EUV lithography.
Research hub imec, along with ASML and TSMC, presented the co-integration of complementary two-dimensional channel transistors on a single 300mm wafer at the IEEE/JSAP Symposium on VLSI Technology and Circuits, according to Tom's Hardware. The pilot-line demonstration achieved a 50nm contacted poly pitch, which represents the tightest pitch recorded to date for complementary 2D devices and rivals modern silicon dimensions. Intel's 10nm-class process, for perspective, features a 54nm contacted gate pitch.
The demonstration integrated n-channel devices using molybdenum disulfide alongside p-channel devices based on tungsten diselenide or tungsten disulfide, according to Tom's Hardware. Imec reported that 94% of the fabricated transistors switched correctly, producing an on/off current ratio greater than 100,000. Both device polarities shut off completely at zero gate voltage, with the tungsten diselenide p-channel transistors approaching top lab-scale metrics to bridge the historic performance gap in p-type 2D logic.
A single exposure on standard 0.33-NA extreme ultraviolet scanners patterned the 28nm channel lengths, according to Tom's Hardware. ASML noted that EUV resolution eliminated the need for multi-patterning schemes or High-NA systems while shrinking channels far below the dimensions left by earlier 300mm runs relying on older lithography. Gouri Sankar Kar, vice president of R&D for compute and memory device technologies at imec, stated that the team achieved the 50nm pitch without degrading the performance of the nFETs or pFETs.
Historically, high contact resistance has restricted 2D transistor scaling because metal contacts pin the semiconductor's Fermi level, creating a Schottky barrier that impedes current through sub-nanometer-thick channels, according to Tom's Hardware. To resolve this without relying on large contact areas, the consortium reversed the traditional fabrication sequence. Engineers patterned tungsten-filled contact trenches first, transferred the monolayer channel material over the contacts, and subsequently deposited the gate on top. Imec credited this bottom-contact thin-film flow for the devices turning fully off at zero bias.
Despite the milestone, substantial integration barriers remain before high-volume manufacturing is feasible, according to Tom's Hardware. The process currently operates as quasi-CMOS, placing the n-type and p-type materials side by side via film transfers rather than monolithic wafer-scale growth. Transitioning the technique to production requires solving residue-free monolayer transfer at manufacturing throughput, refining fab-compatible low-resistance contacts, establishing controllable doping, and assembling long-term reliability data.
TSMC vice president and chief technology officer Dr. Min Cao noted that the joint effort focuses on de-risking the lab-to-fab transition for novel materials, according to Tom's Hardware. With TSMC having commenced volume production on its N2 nanosheet node late last year and complementary FETs expected next, 2D channels remain a long-term roadmap target. Imec projects complementary FETs around 2033 and 2D semiconductors near 2041, while the IRDS roadmap slots 2D channels into the 0.7nm node around 2034, likely starting in back-end or backside-power roles.
