Intel's 18A-P Process Enters Risk Production, Enhancing Foundry Offerings

Intel's enhanced 18A-P process has entered risk production, offering a 9% performance uplift or an 18% reduction in power consumption compared to the base 18A node, according to Tom's Hardware and The Register.

Chips & Climate Desk
Updated Nov 7, 2026 2 min read
Intel's 18A-P Process Enters Risk Production, Enhancing Foundry Offerings

Intel has advanced its foundry roadmap by pushing its performance-optimized 18A-P process into risk production, according to reports from Tom's Hardware and The Register. Disclosed at the IEEE's 2026 VLSI Symposium in Hawaii, this milestone represents an enhancement of the foundational 18A node. Risk production involves initial low-volume manufacturing on a standard production line to gather data on defect rates, performance, and variability before mass production begins.

According to Tom's Hardware, testing on an Arm core subblock at 0.75 volts showed that 18A-P delivers a 9 percent improvement in frequency at iso-power, or alternatively an 18 percent reduction in power consumption at the same performance level. The Register notes these gains are achieved through a mix of transistor, interconnect, and design technology co-optimizations, while maintaining full design rule compatibility with foundational 18A layouts.

Because 18A-P shares the same libraries at cell heights of 180mm for High Performance and 160mm for High Density, chips designed for 18A can reportedly be transferred to the newer process easily. Tom's Hardware explains that while Intel is introducing new transistor options and threshold voltage pairs to expand designer flexibility, utilizing them is not required to gain minor performance benefits from a direct port.

Tom's Hardware details that the 18A-P update introduces three new transistor designs and a new threshold voltage pair called ULVTLL, which offers better performance than LVT with lower leakage than ULVT. Furthermore, the revision brings a 20 to 40 percent improvement in thermal resistance achieved by grinding the wafer down with advanced electronic design automation tools, alongside a 10 to 30 percent improvement in via resistance at performance-critical layers.

In addition to 18A-P, Intel disclosed work on other variants, including 18A-PT which is optimized for through-silicon vias to support chiplet stacking, according to The Register. Industry observers expect AI accelerator designers to favor this variant for integrating separately manufactured memory tiles during packaging. Meanwhile, base 18A is currently ramping in two United States fabs, featuring in Panther Lake and Xeon 6+ products.

Reflecting on the foundational node's trajectory, The Register notes that Intel chief financial officer David Zinsner admitted the company attempted too much at once during early development. Despite past yield challenges and delays, Intel Foundry executive Naga Chandrasekaran stated at the VLSI event that the recent updates and presentations signal a long-term commitment to leading-edge process innovation for customers and partners.
