Chinese Startup Claims DUV-Free Photonic Chip Production via Nanoimprint
Chinese startup Prinano claims to have validated mass production of 8-inch photonic chip wafers using nanoimprint lithography, bypassing DUV systems and reducing manufacturing costs to roughly one-tenth of traditional processes.
Prinano, a Chinese semiconductor startup, claims to have validated the mass production of 8-inch photonic chip wafers without using industry-standard deep-ultraviolet (DUV) lithography. According to Tom's Hardware, the company announced this achievement in a June 5th WeChat post, noting that the wafers were produced in collaboration with Shenzhen Litra Technology. This development is part of a broader effort in China to mitigate reliance on ASML tools currently subject to export restrictions.
Instead of the optical projection used in DUV or EUV systems, Prinano utilizes its PL-AS vacuum air-cushion nanoimprint lithography (NIL) platform. As reported by Tom's Hardware, this system physically presses nanoscale structures into a resist layer, effectively stamping patterns directly onto the wafer surface. The platform incorporates proprietary process technologies, customized double-layer imprinting materials, and wafer-level pressure control to achieve features smaller than 10 nanometers.
The shift from complex optical systems to physical imprinting allows Prinano to claim a significant reduction in capital and operational overhead. According to Tom's Hardware, the company asserts that this nanoimprint process can lower manufacturing costs to roughly one-tenth of those associated with traditional DUV-based workflows. By eliminating the need for the expensive optics found in high-end lithography machines, the startup aims to streamline the production of photonic components.
Prinano is not targeting the production of AI accelerators or high-end processors. Instead, the focus is on photonic chips used in LiDAR, sensing systems, fiber-optic communications, and data center interconnects. Tom's Hardware notes that photonic structures, such as ring resonators, gratings, and waveguides, are particularly well-suited for NIL because they often consist of repeating nanoscale patterns that are easier to replicate via imprinting than the demanding alignment requirements of advanced logic chips.
The use of 8-inch wafers suggests a move toward commercial viability, as this size is common in power electronics and compound semiconductors. This approach mirrors other Chinese efforts to bypass export controls, such as Huawei's LogicFolding architecture. Tom's Hardware highlights that these alternative manufacturing pathways are critical as access to ASML's EUV and DUV equipment becomes increasingly constrained under US-led controls.
Despite the claims of mass production validation, several critical technical metrics remain undisclosed. Tom's Hardware points out that Prinano has not provided data on defect densities, production volumes, yield rates, or customer shipments. Furthermore, there has been no independent third-party validation of these claims, leaving the industry to question whether the process is commercially viable or merely technically feasible.
